Configuration
3-10
You can press the button on the buttom right corner to display the network
status, as shown below.
Note: The maximum transmit link speed of this wireless USB adpater is 150 Mbps and
the maximum receive link speed is 300 Mbps.
Figure 3-8. Network Status
You can also double-click one of the access points on the list to display its general,
WPS, CCX and 802.11n information, as shown below.
Figure 3-9. Access Point Status
The network supports 802.11g connections
The network supports 802.11n connections
Table 3-2. Icon Indications
Icons Description
