3-10
KT3 Ultra2-C ATX Mainboard
MS-6712 ATX Mainboard
USB RMD- The system will boot from USB-interfaced ARMD
HDD device, such as MO or ZIP drive, that functions as hard
disk drive.
Disabled Disable this sequence.
Try Other Boot Devices
Setting the option to Yes allows the system to try to boot from other
devices if the system fails to boot from the 1st/2nd/3rd boot device.
S.M.A.R.T. for Hard Disks
This allows you to activate the S.M.A.R.T. (Self-Monitoring Analysis & Re-
porting Technology) capability for the hard disks. S.M.A.R.T is a utility that
monitors your disk status to predict hard disk failure. This gives you an op-
portunity to move data from a hard disk that is going to fail to a safe place
before the hard disk becomes offline. Settings: Enabled, Disabled.
BootUp Num-Lock
This item is to set the Num Lock status when the system is powered on. Set-
ting to On will turn on the Num Lock key when the system is powered on.
Setting to Off will allow end users to use the arrow keys on the numeric keypad.
Setting options: On, Off.
Floppy Drive Swap
Setting to Enabled will swap floppy drives A: and B:.
Floppy Drive Seek
This setting causes the BIOS to search for floppy disk drives at boot time.
When enabled, the BIOS will activate the floppy disk drives during the boot
process: the drive activity light will come on and the head will move back and
forth once. First A: will be done and then B: if it exists. Setting options:
Disabled, Enabled.
MSI Reminds You...
1. Available settings for “1st/2nd/3rd Boot Device” vary de-
pending on the bootable devices you have installed. For
example, if you did not install a floppy drive, the setting “Floppy”
does not show up.
2. If you want to boot from any of the USB-interfaced devices,
please set USB Legacy Support to All Device.
