Getting Started
† 1 x RJ-45 port (with LEDs)
† 8 x USB ports (front*4 and rear*4)
† 2 x SATA ports
Networking
† Broadcom BCM5705 Gigabit Ethernet controller
Audio
† AC’97 link controller integrated in VIA VT8237R
† 8-channel audio codec Realtek ALC850
- Compliance with AC97 v2.3 Spec
- Meets PC2001 audio performance requirement
Power Management Features
† Wake up on LAN (WOL), wake up on PCI
† RTC alarm and wake up
† Wake up on keyboard/mouse/USB from S1
† Supports ACPI S1, S4, S5 function
System Management
† SMBus (I2C)
† Temperature, voltage, and fan monitors
† Chassis intrusion
BIOS
† The mainboard BIOS provides “Plug & Play” BIOS which detects the peripheral
devices and expansion cards of the board automatically
† The mainboard provides a Desktop Management Interface (DMI) function which
records your mainboard specifications
† Supports boot from LAN, USB Device 1.1 & 2.0, and SATA HDD
Dimension
† ATX Form Factor: 12.0 x 10.0 inch (H x W)
Mounting
† 9 mounting holes (ATX Form standard)
MSI Reminds You...
To create a bootable RAID volume for a Windows 2000 environment,
Microsoft’s Windows 2000 Service Pack 4 (SP4) is required. As the
end user cannot boot without SP4, a combination installation CD must
be created before attempting to install the operating system onto the
bootable RAID volume.
To create the combination installation CD, please refer to the follow-
ing website:
http://www.microsoft.com/windows2000/downloads/servicepacks/
sp4/HFdeploy.htm
