3.4 Restarting the Antenna
To restart the antenna, use the Restart Antenna menu. The
antenna will re-initialize and reacquire the satellite.
Figure 3-6
Restart Antenna Menu
3.5 Operations Mode
This sequence of menus allows a user to view system
information, perform various antenna functions, access internal
sensor functions, and set the display brightness.
Figure 3-7
Operational Mode Sequence
64
TracVision G8 Owner’s Manual - Guide to Technical Information
Restart antenna?
Yes Next Return
Antenna Restarted
Proceed to Section 3.5,
"Operations Mode"
This screen is displayed for 3 seconds
before returning to startup sequence
and main display
Get Antenna Status?
Yes Next Return
Control Antenna?
Yes Next Return
Operations Mode?
Yes Next Return
Control COMPASS?
Yes Next Return
Return to Section 3.3,
"Installing Satellites"
Set Brightness?
Yes Next Return
A B C
D
54-0198
