Port-based port mirroring
Command: /cfg/pmirr/monport <port number>
[Port 1 Menu]
add - Add "Mirrored" port
rem - Rem "Mirrored" port
delete - Delete this “Monitor” port
cur - Display current Port-based Port Mirroring configuration
The following table describes the port-based Port Mirroring Configuration Menu options.
Table 187
Port Mirroring Configuration Menu options
Command Description
add <mirrored port> in|out|both
Adds the port to be mirrored. This command also allows you to
enter the direction of the traffic. It is necessary to specify the
direction because:
• If the source port of the frame matches the mirrored port and
the mirrored direction is ingress or both (ingress and egress),
the frame is sent to the mirrored port.
• If the destination port of the frame matches the mirrored port
and the mirrored direction is egress or both, the frame is sent
to the monitoring port.
rem <mirrored port>
Removes the mirrored port.
delete
Deletes this monitored port.
cur
Displays the current settings of the monitoring port.
