Physical description of the FortiGate-5140 chassis
The FortiGate-5140 chassis is a 12U chassis that can be installed in a standard 19-inch
rack. Table 3 describes the physical characteristics of the FortiGate-5140 chassis.
Table 3: FortiGate-5140 chassis physical description
Dimensions 21 x 19 x 16.8 in. (53.3 x 48.3 x 42.7 cm)
(H x W x D)
Shipping weight
completely assembled
with packaging
110 lb. (50 kg)
Operating environment Temperature: 32 to 104°F (0 to 40°C)
Relative humidity: 5 to 95% (Non-condensing)
Storage environment Temperature: -13 to 158 °F (-25 to 70°C)
Relative humidity: 5 to 95% (Non-condensing)
Power consumption Maximum: 2,980W DC
Power input 2x redundant -48VDC to -58VDC
