PowerTALK 101
22
PowerTALK 101 specifications
Item PowerTALK 101 PowerTALK 101B
Serial ports 2x RS-232, DB-9 male Ditto
Serial port settings 1200-19200 bps, 5,6,7 or
8 bits, N/O/E parity, 1,2
stop bits
Ditto
Serial port signals supported Tx, Rx
Handshake signals high
Ditto
Also DTR and flow control
Maximum recommended 3 wire serial
port speed
19200 baud Ditto
Ethernet standard IEEE-802.3 CSMA/CD Ditto
Ethernet speed 10 MB/s Ditto
Ethernet medium 10 Base-T unless
otherwise specified
Optional 10 Base-2
Optional 10BASE-5 or
10BASE-FOIRL
Ditto
IP address Unique fixed IP & user
definable IP
Ditto
Ethernet mode UDP broadcast only Ditto
Also UDP peer to peer
Network traffic burden Depending on settings:
From 8kbps (3840
packets/s) to 1Mbps
(30packets/s) for a 19200
bps serial data flow
Ditto
Supervision Watchdog timer checks for
continuous program
execution
Ditto
Isolation: PSU Input voltage to earth 2.5 kV RMS Ditto
Isolation: PSU Output voltage to earth 2.5 kV RMS Ditto
Isolation: RS-232 to earth 2.5 kV RMS Ditto
Electrical terminals Phoenix Contact terminals
MTK-P/P, UK5-N, UK4-TG
Ditto
Processor type Intel 486 Ditto
Processor memory type DRAM modules, FLASH
RAM chips
Ditto
Processor mode Protected mode Ditto
Energy saving (radiated heat
reduction)
Processor normally used
or switched to standby
mode
Ditto
Configuration User set by PT.EXE, using Ditto
