High Efficiency “HE” detergent compartment
This compartment holds liquid or powdered HE detergent for
your main wash cycle.
Liquid fabric softener compartment
Automatically dilutes and dispenses liquid fabric softener at
the optimum time in the cycle.
n
Use only liquid fabric softener in this dispenser.
Liquid chlorine bleach compartment
Automatically dilutes and dispenses liquid chlorine bleach at
the optimum time during the first rinse after the wash cycle.
This compartment cannot dilute powdered bleach.
B
C
A
B
A
HE detergent
Liquid fabric
softener
Chlorine bleach
8
C
Choosing the Right Detergent
Use only High Efficiency detergents. The package will be marked
“HE” or “High Efficiency.” Low-water washing creates excessive
sudsing with a non-HE detergent. Using non-HE detergent will likely
result in longer cycle times and reduced rinsing performance. It may
also result in component failure and, over time, buildup of mold or
mildew. HE detergents are low-sudsing and quick-dispersing to
produce the right amount of suds for the best performance. They
hold soil in suspension so it is not re-deposited onto clean clothes.
Follow the manufacturer’s instructions to determine the amount of
detergent to use.
Use only High Efficiency (HE) detergent.
A
C
B
7
DISPENSER DRAWER
The dispenser drawer gives you the convenience of automatically
adding HE detergent, liquid chlorine bleach, and liquid fabric
softener to the wash load at the proper time. See “Using the
Dispenser Drawer” for information on using the dispenser drawer.
CYCLE STATUS LIGHTS
Delay
If a Delay Start is set, the Delay indicator
will light and the delay time will count down
in the display.
Door Locked
Door Locked will light to indicate that
the door is locked and cannot be opened
without first pausing or canceling the cycle.
Add a Garment
When “Add a Garment” is lit, you may pause
the washer, open the door, and add items.
Touch and hold START to start the washer again.
Done
Once the cycle is complete, this light will come on.
Remove the load promptly for best results.
Adding HE detergent to dispenser
Powdered detergent:
Lift the selector to the high
position.
Liquid detergent:
Push down the selector to the
low position.
Pour a measured amount of HE
detergent into detergent compartment.
For powdered detergent, lift the selector
to the high position. For liquid detergent,
push down the selector to the low
position.
Do not overfill; adding too much detergent
may cause detergent to be dispensed into
the washer too early.
Use only High Efficiency
(HE) detergent.
IMPORTANT:
n Do not add single-dose laundry packet to dispenser drawer.
n Use powdered detergent when using the Delay Start option.
Liquid detergent may seep out before the wash begins.
HE detergent
compartment
1. Open the dispenser drawer.
2. Add laundry products as described in steps 4–6 in the
“Using Your Washer” section.
3. Slowly close the dispenser drawer. Make sure it is
completely closed.
NOTE: A small amount of water may remain in the dispensers from
the previous wash cycle. This is normal.
USING THE DISPENSER DRAWER
Selector
Selector
in high
position
Selector
in low
position
