CONTROL PANEL AND FEATURES
3
6
5
Not all features and cycles are available on all models.
NOTE: The control panel features a sensitive surface that responds
to a light touch of your finger. To ensure your selections are
registered, touch the control panel with your finger tip, not your
fingernail. When selecting a setting or option, simply touch its name.
Models MHW5100D and MHW3100D
POWER/CANCEL
Touch to turn the washer on and off. Touch to stop/cancel
a cycle at any time.
NOTE: Turning the Wash Cycle knob will also turn the washer
on and off.
WASH CYCLE KNOB
Turn the knob to select a cycle for your laundry load.
An LED will light up for the cycle selected.
NOTE: The Clean Washer with affresh
®
LED will flash when the
washer has run 30 wash cycles as a reminder to run the Clean
Washer with affresh
®
cycle.
See “Cycle Guide” for detailed descriptions of cycles.
START
Touch and hold until the light above START comes on to start
a cycle, or touch once while a cycle is in process to pause it.
If you want to add a garment, you can touch START when the
“Add a Garment” LED is on.
LED DISPLAY AND SETTINGS
When you select a cycle, its default settings will light up and the
Estimated Cycle Time will be displayed (for times longer than 60
minutes, hours will be displayed, followed by minutes). Factors
such as load size, wash temperature, and water pressure may
affect the time shown in the display during the cycle. Tightly
packing garments, unbalanced loads, or excessive suds may
cause the washer to adjust the cycle time, as well.
Touch the desired setting along the right of the display to adjust.
See “Cycle Guide” for available settings on each cycle. Not all
settings are available with all cycles.
Temperature
The recommended wash temperature is preset for each cycle.
You may also select a wash temperature based on the type
of fabric and soils being washed. For best results, follow the
garment label instructions. All wash temperatures feature a cold
rinse.
1
2
3
4
2
1
Soil Level
The Soil Level setting (wash time) is preset for each wash
cycle. For most loads, use this preset soil level. When
you change the soil setting, the cycle time will increase or
decrease in the Estimated Cycle Time display.
For heavily soiled and sturdy fabrics, use the Soil Level
setting to select more wash time. For lightly soiled and
delicate fabrics, use the Soil Level setting to select less
wash time. Lower soil level settings will help reduce
tangling and wrinkling.
Spin Speed
This washer automatically selects the spin speed based
on the cycle selected. Some preset speeds can be
changed.
• Higher
spin speeds mean shorter dry times, but may
increase wrinkling in your load.
•
Lower spin speeds reduce wrinkling, but will leave
your load more damp.
DELAY START
Use + and – to delay the start of the wash cycle by up
to 9 hours. To turn off Delay Start, use + and – to set the
delay time to “0,” or touch POWER/CANCEL.
OPTIONS
Touch to activate additional wash options or additional
features on the washer. Not all options are available
on all models.
Extra Rinse
Activate this option to add an extra rinse to most cycles.
Control Lock
Touch and hold for 3 seconds to lock the controls
to avoid unwanted changes or operation. Touch and
hold 3 seconds again to unlock. For each second
CONTROL LOCK is held down, the display will count
down one second: you will see “3,” then “2,” then
“1.” You may still touch START to pause the cycle,
or touch POWER/CANCEL to turn off the washer.
B
A
7
A
B
5
4
4
6
