17
DIAGNOSTIC CODES
If the setup mode is entered and one of the following has occurred, the appropriate diagnostic
code will be in the display.
(For different code consult service personnel)
WASHER HELP MODE
This mode is entered by pressing the PERMANENT PRESS keypad while in special pricing
option mode 2.XX (or while dAS displays if operating with Maytag Data Acquisition setup).
In help mode, other display symbols and elements are mapped to reflect the state of various
inputs and outputs as follows:
CLEANING YOUR WASHER
Cleaning the Door Seal/Bellow
1. Open the washer door and remove any clothing or items from the washer.
2. Inspect the black colored seal/bellow between the door opening and the basket for
stained areas. Pull back the seal/bellow to inspect all areas under the seal/bellow and to
check for foreign objects.
3. If stained areas are found, wipe down these areas of the seal/bellow, using the procedure
that follows.
a) Mix a dilute solution, using ³₄ cup (177 mL) of liquid chlorine bleach, and 1 gal.
(3.8 L) of warm tap water.
b) Wipe the seal/bellow area with the dilute solution, using a damp cloth.
c) Let stand 5 minutes.
d) Wipe down area thoroughly with a dry cloth and let the washer interior air dry with
door open.
IMPORTANT:
■ Wear rubber gloves when cleaning for prolonged periods.
■ Refer to the bleach manufacturer’s instructions for proper use.
Washer Maintenance Procedure
This washer has a special cycle that uses higher water volumes in combination with
AFFRESH™ washer cleaner or liquid chlorine bleach to thoroughly clean the inside of the
washer.
NOTES:
■ Read these instructions completely before beginning the cleaning process.
■ If necessary, the cleaning cycle may be interrupted by pressing the DELICATES & KNITS
button twice. However, this will not immediately stop the cycle. The machine will
continue with several rinse and drain steps to ensure that all remaining bleach is rinsed
from the washer.
d5 Blocked coin 1 or coin drop control circuit failure (coin recognition and price
display disabled while blockage persists). PR Models Only: Setup mode J. should
be set to _d (or Ed if in Enhanced Debit) to eliminate coin related diagnostic
codes.
d9 Voltage detected below 90 vac for 8 seconds.
d13 Blocked coin 2 or coin drop control circuit failure
(coin recognition and price display disabled while blockage persists).
d16 Not receiving communications from installed debit card reader in
Generation 2 debit mode.
F20 Slow Fill. The washer will not detect water input for 4 min. Pressure switch failure
or no water inlet. This code is reported as d8 on d7
F22 The door is not able to lock. Door lock error or someone trying to start the washer,
by pressing the door switch with the finger. This code is reported as d17 on Accu
Trac.
Wash Water sensed at wash level
* Low voltage present (below about 90 vac)
Circle above digit Door closed
DOOR LOCKED Door sensed locked
COLD Cold water relay on
HOT Hot water relay on
OR Door unlock
AVAILABLE Drain pump ON
A.Seal/Bellow
A
