MOTOR, BASKET AND TUB PARTS
6
For Model: MTW6300TQ0
(White)
W10131043
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
W10108420
Tub Ring
2 8566491 Dispenser,
Fabric Softener
3
W10074580
Cap, Barrier
4
W10072840
Seal, Inner Cap
5
W10076310
Agitator, Assembly
(Complete)
6
W10076270
Screw & Washer
Assembly
7
W10076260
Washer
8
W10076210
Cam, Agitator
9 8558884 Roller, Agitator
Cam (Set of 4)
10 8578563 Spacer, Thrust−Cam
11 8577284 Auger, Agitator
12 8566279 Spacer, Thrust
13
W10076190
Agitator
14 8533953 Screw,
8−16 X 1.000 (6)
15
W10118114
Hub, Basket−Driven
(Includes Item 16)
16 8545953 Hub, Basket−Driver
(Includes Item 15)
17
W10118180
Basket Assembly
(Includes Items
14, 15, & 16)
18 8572660 Tub & Drive Shaft
Assembly
19 8566197 Filter, Dual
Pump Hood
20 8533928 Screw,
8−18 X 3/4 (2)
21 8542674 Weight
Tub Counterbalance
22
W10004910
Screw,
12−16 X 1−1/4 (2)
23 8565172 Tub, Buffer
(Set of 4)
24 8557839 Shield,
Drive Motor
(Includes Item 23)
25 8557836 Plate, Stator
(Set of 2)
26 8565188 RPS Assembly
27 8565170 Stator, Motor
(Includes Item 25)
28
W10076010
Screw,
1/4−20 X .968 (4)
29 8565177 Rotor, Main Drive
Motor (Includes
Item 30)
30 Bolt, Rotor
Assembly
Non−Serviceable
(Supplied W/Rotor)
31 8572540 Hose, Pressure
Switch
32
W10058730
Harness, Lower
(Includes Item 31)
33
W10005430
Clamp, Pressure
Hose Retainer
34 8533957 Screw, 10−16 X 1/2
