TOP AND CABINET PARTS
2
For Model: MTW6300TQ0
(White)
W10131043
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10092684
Use & Care Guide
W10092700
Tech Sheet
W10092691
Quick Start Guide
8577781 Wiring Diagram
W10092738
Energy Guide
2
W10058300
Top
3
W10114656
Frame Assembly,
Cabinet Top
(Includes
Items 31 & 38)
4 3390647 Screw, 8−18 X 1/2
5 8566156 Cabinet
6 8566090 Panel, Rear
7 8543781 Retainer, Drain
Hose Storage
8 8576784 Sound Absorber,
Cabinet
9
W10111536
Ball,
Suspension (4)
10 8564009 Damper Assembly,
Tub Suspension
(Set Of 4−Includes
Items 45 & 46)
11 1157158 Screw, 8−18 x 3/8
12
W10042120
Locator, Top (2)
13
W10119828
Screw, Lid
Hinge
Mounting (4)
14 8576780 Hinge Arm, Lid (2)
15 Hinge, Spring
Assembly
8563958 (Left)
8563959 (Right)
16 8565184 Absorber, Sound
(Bottom)
17
W10052730
Bearing, Lid
Hinge (2)
18
W10093736
Liner, Lid
(Includes Item 48)
19 8572891 Lid
20 8578826 Foot Assembly,
Leveling (4)
21 3400076 Screw, 10−32 x 5/8
22 8281736 Wire,
Ground Jumper
23
W10059160
Dispenser, Bleach
24 8566211 Bezel, Bleach
Dispenser
25 8564976 Dispenser,
Detergent
26 8576772 Bezel, Detergent
Dispenser
27
W10106990
Nozzle Assembly,
Fresh Water
28 371503 Clamp, Hose
29
W10059230
Lock Assembly, Lid
30 8572019 Bezel, Lid Lock
31 8564458 Absorber, Impact
32 8564456 Hinge, Top (2)
33 18849 Pad, Top Hinge (2)
34 343641 Screw,
10−16 x 1/2 (2)
35 8563941 Cover, Harness
36 693995 Screw, 8−18 x 3/8
37 8543784 Bracket,
Drain Hose
38 8578386 Shield, Wire
Harness
39 8281136 Screw, 10−16 x 3/4
40 8576476 Spacer, Rear
(Cabinet/Top)
41 370451 Clamp, Hose
42 371503 Clamp, Hose
43 3400061 Screw,
10−16 x 9/16
44 90016 Clip, Harness (5)
45 8577896 Washer, Suspension
Umbrella (4)
46 8564017 Cup,
Suspension (4)
47 8563785 Lock, Top−
Front (2)
48
W10076780
Bumper, Lid (2)
49
W10076920
Screw (2)
