Maytag MED9700SQ0 Clothes Dryer User Manual



BULKHEAD PARTS
6
For Models: MED9700SQ0, MED9700SB0
(White) (Black)
8181446
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 8575324 Shaft, R.H. Thread
2 3390647 Screw, 8−18 x 1/2
3 3394984 Door,
Lint Screen
4 3406653 Harness, Sensor
5 697354 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3934666 Nut
9 8066208 Clip−Spring
10 3402841 Lens,
Drum Light
11 489463 Screw, 8−18 x 5/8
12 8572105 Clip, Exhaust
Pipe
13 90767 Screw, 8−18 x 3/8
14 3387747 Heater Element
15 279457 Terminal Wire
Kit (For Heater
Element Wiring
Harness Repair)
16
W10001120
Nut
17 8520836 Bulkhead, Rear
18 3387459 Washer, Support
19 8575325 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 8563745 Exhaust Pipe
23 3394985 Housing, Outlet
24 8529007 Plug,
Rear Bulkhead
25
W10113138
Complete Drum
Assembly
26
W10109200
Screw, 11−16 x 3/4
27
W10166807
Seal, Drum
28 695240 Screw, 8−18 x 1/2
29 8533971 Screw, 8−18 x 5/16
30 8519221 Channel Bracket,
Rear Bulkhead (2)
31 8571651 Bracket, Upper
Rear Bulkhead
32 3357011 Screw, 10−16 x 1/2
33 3406124 Bulb, Light
34 3387223 Electrode, Sensor
35 3977373 Bracket,
Drum Light
36
W10136369
Socket Assembly
37 697772 Wheel, Blower
38 3392519 Thermal Fuse
39 3394986 Spring, Lint
Screen Door
40 697770 Seal, Cover Plate
41
W10049370
Lint Screen
42 8577274 Thermistor
43 487909 Screw, 8−15 x 1/2
44 8544362 Housing, Blower
45 8066168 Lint Duct Assembly
46 3392537 Heater Box
47 8318314 Thermal Cut−Off
(Includes
Illus. 48)
48 3391914 Thermostat 295
F
(146
C)
49 8066099 Bracket,
Heater Box
50 8299979 Grill, Outlet
51 3387230 Screw, 10−16 x 1
52
W10113136
Baffle, Drum
53 8519245 Bulkhead, Front
