Maytag MED9700SQ0 Clothes Dryer User Manual



TOP AND CONSOLE PARTS
2
For Models: MED9700SQ0, MED9700SB0
(White) (Black)
8181446
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10150616
Use & Care Guide
8563816 Tech Sheet
W10099080
GUIDE,
QUICK START
2 Top
8519251 White
8579997 Black
3 8576530 Harness, Main
4 Panel, Console
(Includes Bezel,
Light Indicators
& Endcaps)
W10098940
White
W10098960
Black
5 3394427 Clip, Harness
6 8519271 Bracket, Console
7 353424 Connector, Sensor
8 94614 Terminal
9 3936144 Plug, Terminal
10 94613 Terminal
11 3390647 Screw, 8−18 x 1/2
12 488886 Screw, 8−18 x 1/2
13 8542690 Bezel, Cycle
14 3936150 Connector,
7−Circuit
15 3395683 Connector,
(Motor)
17 2203186 Connector,
5−Circuit
18 Knob Assembly
W10133964
White
8580138 Black
19 8558455 User Interface
(Includes
Illus. 28, 29
& 30)
20 EndCap(LH)
8562598 White
8580135 Black
21 EndCap (RH)
8562597 White
8580134 Black
22 8542682 Light Indicator
(Status)
23 8542683 Light Indicator
(Cycle)
24 8542691 Lens, Display
25 8542684 Light Indicator
(Dryness Level)
26 8542685 Light Indicator
(Temperature)
27 8542686 Light Indicator
(XCare/EOC)
28 8542717 Shaft,
Cycle Selector
29 8542716 Bearing, Knob
30 8542715 Spring, Knob
31 Pushbutton,
(Control)
W10133970
Silver
8580140 Silver
(For Black Model)
32 Pushbutton,
(Drytime)
W10100390
White
8579989 Silver
33 Pushbutton,
(Dryness/Temp)
8562604 White
8579991 Silver
34 Pushbutton,
(XCare/EOC)
8562605 White
8579993 Silver
35 Pushbutton
(Start/Cancel)
W10133971
Silver
8579994 Silver
(For Black Model)
