BULKHEAD PARTS
6
For Model: MED6600TQ0
(White)
W10167170
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 8544805 Lint Chute
Assembly
2 487909 Screw, 8−15 x 1/2
3 3387459 Washer−Support
4 347139 Seal, Lint
Chute
5 90767 Screw, 8−18 x 3/8
6 8573836 Shield, Exhaust
7 3392519 Thermal−Fusse
(91
C)
8 8577891 Thermostat,
HI−Limit
9 3977393 Thermal Cut−Off
(Includes
Illus. 8)
10 694089 Wheel, Blower
11 8577230 Housing, Blower
12 8546149 Clip−Heater Box
13 343641 Screw, 10−16 x 1/2
14 8544801 Box, Heater
15
W10053480
Bracket,
Lint Chute
16 3977373 Bracket, Drum
Light
17 3403585 Element, Heater
18 8544813 Seal
19 279457 Wire Kit, Terminal
(For Heater
Element Wiring
Harness Repair)
20 489463 Screw, 8−18 x 5/8
21 3196537 Screw
22 3406126 Bulb
23 8558890 Bulkhead, Front
24 3402841 Lens, Drum Light
25 690997 Ring Tri
26 8575325 Shaft, (L.H.)
27 8575324 Shaft, (R.H.)
28 8536973 Roller, Support
29
W10001120
Nut, 3/8−16
30 8576468 Assembly, Sensor
31
W10131528
Bulkhead, Rear
32 3934666 Nut 3/8−16 (R.H.)
33
W10044579
Washer−Nozzle
34
W10044628
Nut, Brass
9/16 − 24 x 1/2
35 8557277 Seal Drum (2)
36
W10109200
Screw, 11−16 x 3/4
37 8557270 Drum, Assembly
38 8565688 Baffle, Drum (3)
39
W10168632
Socket Assembly
40 8577274 Thermistor
41 8544810 Collar, Lint Chute
42
W10044629
Nozzle & Screen
Assembly
43
W10153864
Nozzle & Hose
Assembly
(Includes Items
33,34,42,46)
44
W10146150
Valve & Bracket
Assembly
45
W10153865
Sleeve, Tube
46
W10131527
Hose Assembly
(Not Servicable)
47
W10158778
Foam, Bracket
48
W10160610
Harness,
Water Valve
49
W10044605
Coupling, Hose
50
W10160575
Cover, Myst Valve
51 693995 Screw, 8−18 x 3/8
52
W10044615
Clip,
Push−To−Connect
53
W10153129
Valve & Hose
Assembly
