CABINET PARTS
4
For Model: MED6600TQ0
(White)
W10167170
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 18849 Pad, Top Hinge
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, 8−18 x 3/8
4
W10007520
Clip, Ground (2)
5
W10110241
Cover, Block
6 8576625 Lock−Top Front (2)
7
W10140148
Panel, Rear
8 3404413 Plug−Hole
9 8568303 Locator,
Snap Down
10 3978977 Door Switch
Assembly
11 3389420 Retainer, Idler
12 8575027 Seal, Door
13 342055 Pal Nut (4)
14 8578538 Restrainer, Belt
15 3394083 Clip, Front
Panel (2)
16 3392100 Foot, Dryer
279810 Foot−Optional
(Extended Length
Package of 2)
(Not Included)
17 279318 Terminal, Tinned
& Brass (3)
(Includes Illus. 39)
18 8557569 Cabinet
19
W10076060
Gasket, Inner Door
20 3387374 Spring, Idler
21 8565029 Panel, Front
22 8566208 Switch Assembly
23 660658 Clamp, Motor
24 8572982 Catch, Door
Assembly
25 8578560 Plug, Hole
26 3393008 Screw, 10−16 x 1/2
27 3390631 Screw, 8−18 x 1/2
28 8565018 Hinge, Assembly
29 8564011 Bracket, Switch
30 8539897 Belt−Switch
Jumper
31 8533974 Screw Ground
32
W10116398
Window, Outer Door
33 8572983 Strike, Door
34 308499 Palnut (10)
35 8565037 Door Inner
36
W10116925
Door, Outer
37
W10111249
Door Handle
38
W10044490
Seal, Front Panel
39 279393 Terminal Block
Kit (For
Terminal Block)
40 342055 Screw, 10−32 x 5/8
41 3397659 Block, Terminal
42 8547174 Pulley Assembly
43 8547168 Belt, Drive
44 8547166 Base, Motor
45
W10002600
Bolt,
6−20 x 1 1/4
46 8578565 Pulley, 60 HZ
47 8566152 Motor Assembly
60 HZ.
48 238088 Hinge, Top (2)
49 8565015 Glass, Inner Door
50
W10100830
Screw,
10−16 x 3/64
