P A R T S A N D F E AT U R E S
1
2
4
Hot and Cold
Water Inlets
Drain
Hose
Rear of Washer
KEY PARTS AND COMPONENTS
In addition to the special features and components outlined in
the Special Features section, there are several other important
components that are referenced in this manual.
3
Included Accessories
Hot and Cold
Water Hoses
Wrench
(for removing
shipping bolts and
adjusting leveling feet)
Tie Strap
(for securing
drain hose)
Elbow Bracket
(for securing
drain hose)
Caps (4)
(for covering
shipping bolt holes)
1
ULTRA-CAPACITY STAINLESS STEEL DRUM
The ultra-large stainless steel drum offers extreme durability
and is tilted to improve efficiency and allow easier access for
large items.
2
WATER CIRCULATION AND STEAM NOZZLES
The water circulation nozzles spray the water/detergent
solution directly onto garments for super cleaning
performance. During LG’s unique high-efficiency STEAM
cycles, the steam nozzle injects fabrics with hot steam to
gently remove tough stains.
3
LEVELING FEET
Four leveling feet (two in the front and two in the back) adjust
to improve washer stability on uneven floors.
4
DRAIN ACCESS PANEL
Provides access to the drain line and drain pump filter.
8
