H O W TO U S E
CONTROL PANEL FEATURES
2
POWER ON/OFF BUTTON
Press to turn the washer ON. Press again to turn
the washer OFF.
NOTE: Pressing the ON/OFF button during a
cycle will cancel that cycle and any load settings
will be lost.
CYCLE SELECTOR KNOB
Turn this knob to select the desired cycle. Once
the desired cycle has been selected, the standard
presets will be shown in the display. These
settings can be adjusted using the cycle setting
buttons anytime before starting the cycle.
START/PAUSE BUTTON
Press this button to START the selected cycle.
If the washer is running, use this button to PAUSE
the cycle without losing the current settings.
NOTE: If you do not press the START/PAUSE
button within 4 minutes of selecting a cycle, the
washer automatically turns off.
STEAM BUTTON
Press the STEAM button to add steam to the
selected cycle for added cleaning power.
NOTE: Steam can only be added to the
following cycles: STEAMFRESH™, SANITARY,
BULKY/LARGE, PERM. PRESS, COTTON/
NORMAL, and ALLERGIENE™.
1
2
CYCLE SETTING BUTTONS
Use these buttons to select the desired cycle
options for the selected cycle. The current
options are shown in the display. Press the
button for that option to view and select
other settings.
DELAY BUTTON
Press this button to delay the start of the wash
cycle. Each press of the button increases the
delay time by one hour, up to 19 hours.
LCD DISPLAY
The display shows the settings, estimated
time remaining, options, and status messages
for your Steam Washer™. The light in the
display will remain on through the cycle.
SPECIAL FUNCTION BUTTONS
The special function buttons allow you to select
additional functions and will light when selected.
Certain buttons also allow you to activate
secondary functions by pressing and holding
the button for 3 seconds.
For detailed information about the individual
functions, please see the following pages.
OPTION BUTTON
Press this button to select additional cycle
options such as WATER PLUS, QUICK CYCLE,
EXTRA RINSE, STAIN CYCLE, and SPINSENSE
™
.
Press the button next to the desired option in the
display to select. The button will light to show
the option has been selected.
5
6
3
4
7
8
1
3
4
7
9
9
6
8 8
5
18
