Equator 3612 Washer/Dryer User Manual



Helpful Hints
Your Washer Dryer features three different speeds during
the wash cycle. During the Cotton cycle the drum spins at
1,200 or 800 rpm depending on how you set it. During
Permanent Press the drum spins at 850 rpm. During
delicates, the drum spins at 500 rpm. When drying heavy
cotton articles such as bath towels or jeans, be sure the
“Regular” washer setting is selected. The faster spinning
will extract more water from these highly absorbent fabrics
and reduce the degree of dampness as the machine goes
into the drying mode. This will cut down on your drying
time.
Use Liquid Fabric Softener. Fill the softener compartment
up to the level marked. Using fabric softener fluffs out
clothes immediately after the wash cycle. This helps speed
drying time and reduce wrinkles.
This Washer Dryer is a 110 Volt machine, so the heating
element requires more time to achieve full heat than a larger
220 volt unit requires. The heating element will take about
10 minutes to reach full heat.
To dry your laundry, the Washer Dryer blows heated air
into the rotating drum. As the drum tumbles your laundry,
the warm air dries it. If the drum is overfilled with laundry,
the air is not allowed to circulate and clothes will not dry
properly.
Use Low sudsing Detergent. This is recommended for all
front loading washers. It ensures there is no over sudsing,
which may reduce the performance of your machine. Also,
this prevents damage to your machine which may be caused
by excess suds entering the condensing chamber and
clogging the fan blower mechanism with lint. If you have
any problem obtaining low sudsing detergent, please call
Equator to obtain information on our house brand, Equator
low sudsing detergent. A coupon for a free box of the
Equator detergent is enclosed with the warranty card.
When sorting laundry always take into consideration the
quantity and type of fabric contained in the load. Highly
absorbent fabrics such as those used in towels or jeans
will absorb more water and become very heavy when
saturated. If you notice that your clothes are taking longer
than usual to dry you may be overloading the machine, or
washing too many highly absorbent articles for a single load.
Your washer dryer operates on 110 volts and has a 1,300
watt dryer. It will take a longer time to dry clothes than a
traditional dryer (which operates on 220 volts, 5,000 watts).
However, with the following tips, you can increase the
efficiency of the dryer.
1. DOOR REMAINS LOCKED DURING DRYING: The door
is electronically kept locked drying cycle, with the
Mode+Door Lock light on. This prevents any starting and
shutting the heater, which in turn conserves energy by
trapping the heat.
2. FABRIC SOFTENER: When the Wash and Dry cycles
are set to run consecutively, the preheat function comes on
automatically. In this, the heater is turned on during the last
spin cycle of the wash program. In the Regular Wash
program, the clothes will be getting spun at 1,200 rpm, while
hot air from the dryer will be entering the drum at the same
time. While centrifugal force causes clothes to stick to the
sides of the drum, the hot air will “bake” them to the sides.
It may take 30 minutes or more for the clothes to unstick
and fall into the drum. USING LIQUID FABRIC SOFTENER
WILL CAUSE THE CLOTHES TO UNSTICK IMMEDIATELY.
THIS HELPS DRY CLOTHES FASTER AND CAUSES LESS
WRINKLES.
3.OVERLOADING: The drum has a capacity of 14 lbs
(1.92 cu. ft.) While this is the largest drum available on any
combination washer-dryer, it is smaller than a standard U.S.
washer. The EZ 3612 CEE drum should not be overloaded.
With too many clothes, airflow is reduced, increasing drying
time. A maximum of 10 lbs OR 2/3 of the drum full of
clothes is recommeded for ideal drying.
4. OVER DRYING: This machine uses a condensing dryer.
In this cold water is used to condense the moisture from
the hot air. Since there is no external exhaust system, the
moisture remains in the machine. Frequently, when it seems
the clothes are damp, it is actually the remaining moisture
(like dew). Take clothes out and within a few minutes they
will be dry. Do not overdry the clothes.
5. USE LOW SUDSING DETERGENT: By using low sudsing
detergent (Equator brand or any other), you are preventing
suds from entering the condensing chamber. When suds
enter the condensing chamber, lint particles can clog up
the chamber and the fan blower. Over time, this reduces
drying efficiency and may require the fan blower (impeller)
to be cleaned.
Dryer Efficiency
Instructions for installation and use
4
