I
nstructions for installation and use 12
How to dry
- During the drying phase, the door tends to get
quite hot.
- Do not use the appliance to dry clothes that have
been washed with flammable or chemical solvents
(e.g. trichlorethylene).
- Do not use the appliance to dry foam rubber or
similar elastomers.
- Make sure that the cold water faucet is turned
on during
the drying cycles.
- This washer-dryer can only be used to dry clothes
which have been pre-washed in water.
WARNING
Fabric
type
Load
type
Max.
load
Lbs (kgs) Extra
Dry
Ward-
robe
Iron
- Cotton,
- Linen
Clothing of
different
sizes
8 (3.5) 100 90 80
- Cotton Terry
towels
8 (3.5) 100 100 90
- Terital,
- Cotton
Sheets,
Shirts
5 (2.5) 80 70 60
- Acrylics Pyjamas,
socks, etc.
2 (1) 60 50 50
- Nylon Slips, tights,
stockings,
etc.
2 (1) 60 50 50
Table A.
Drying time (minutes)
Useful tips
Never use your washing
machine to wash... torn, fraying
or non-hemmed linen. If it is
absolutely neccessary, place it
in a bag for protection. Do not
wash colored linen with whites.
Watch the weights !
For best results, do not exceed
the weight limits stated below
(figures show weight of dry
garments):
- Resistant fabrics:
12 lbs (5.5 kg) maximum
- Synthetic fabrics:
6 lbs 10 oz (3 kg) maximum
- Delicate fabrics:
5 lbs 8 oz (2.5 kg) maximum
- Pure new wool:
2 lbs (1 kg) maximum
- Bathrobe: 5 lbs 8 oz (2.5 kg)
maximum
How much does it weigh?
1 sheet 11/4 lb (400-550 gr.)
1 pillow case 4 oz.(120 gr.)
1 tablecloth 1 lb (450 gr.)
1 bathrobe 2-3 lbs
(900-1,300 gr.)
1 towel 5oz/1 lb (150-500 gr.)
Colored T-shirtss, printed ones
and shirts last longer if turned
inside out before washing.
Printed T-shirts and sweatshirts
should always be ironed inside
out.
Denim Alert.
Some overalls have straps with
hooks that can damage the
drum of your washing machine
or other garments during the
wash. To minimize the risk,
place hooks in the pocket and
fasten with safety pins.
Vacations: unplug the
appliance.
It is recommended that you
should unplug the machine from
the socket and turn off the water
supply. Leave the door ajar to
allow air circulation to the draw
and the door gasket area. This
will prevent unpleasant odours.
Combined (Wash&Dry)
• Look at table A to the side
and follow the instructions
provided for MAX load to have
an automatic washing and
drying cycle.
• Follow the instructions for
wash only (see page 9, the
section "Starting the Washer-
Dryer")
• Set the dryer time on Dryer
knob.
• Press the Power button.
If the laundry load to be
washed and dried exceeds
the maximum load (see table
A), then:
- follow the instructions
provided for wash only (page
9, in section "Starting the
Washer-Dryer" and follow
these instructions.
- when the wash cycle has
finished, remove your
washing, divide it up and
replace part of it inside the
drum.
Now follow the instructions
provided for a dry only cycle.
Repeat this procedure for the
remainder of the load.
Dry only
• Load the clothes no more
than 2/3 full (10 lbs/4.5 kg) for
cottons, (see table for other
fabrics), make sure that:
- the door is shut correctly;
- the plug is inserted in the socket;
- the water tap is turned on;
- Power button has not been
pressed (O position).
• Set the Washer knob to the
appropriate “Reset” setting
depending on the type of fabric
• Set dryer time on the Dryer
knob
• Press Power button to start.
When Drying is Complete...
Mode+ Lock light flashes
slowly. Turn the washer-dryer
off by pressing the Power
button (O position). Now you
can open the appliance door.
Once you have removed the
dry clothes from the appliance,
leave the door open or ajar to
avoid the formation of bad
odors and turn off the water (if
attached with a faucet adapter
kit.)
The data contained in the table are purely indicative.
The drying time depends largely on the type of material (some
fibers absorb more water than others), on the dampness of the
articles when the drying is started and on the amount of the
laundry. Table napkins, towels and similar (rather thick) articles
will take a long time to dry.
For best results, we
recommend you use very
little detergent, taking care
not to wash more than 2 lbs
(1kg) of laundry.
WOOL CYCLE
A combined Washing and Drying Program
For more delicate
garments:
protect underwear,
tights and stockings
and delicate items by
placing them in a
separate bag
For cotton loads of less than 2 lbs (1 Kg), use the drying
program designed for synthetic fabrics.
A spin cycle is carried out during the drying if you have
set a cotton program .
IMPORTANT
