Electrical Connection
This portable washer should be properly grounded for your safety. The power cord of this portable
washer is equipped with a three-prong plug which mates with standard three prong wall outlets to
minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong
from the power cord supplied.
This portable washer requires a standard 110-120 Volts~A.C./60Hz
electrical outlet with three-prong ground.
The cord should be secured behind the portable washer and not left
exposed or dangling to prevent accidental injury.
Never unplug the portable washer by pulling the power cord. Always
grip the plug firmly and pull straight out from the receptacle.
Do not use an extension cord with this appliance. If the power cord is
too short, have a qualified electrician or service technician install an
outlet near the appliance.
Control Panel
1. Water Temperature Indicator
2. Water Level Indicator
3. Wash Mode Selection Indicator
4. Process Selection Indicator
5. Start/Pause Button
6. Power Button
7. Function Selection Button
8. Wash Selection Button
9. Water Level Selection Button
10. Water Temperature Selection Button
?
Warning
?
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Avanti Products service center.
STANDARD 120
VOLTS, 60 HERTZ,
3-WIRE SOCKET
GROUND
1
2
0
1
2
V.A.C.
±
0
V.A.C.
1
1
5
1
2
V.A.C.
±
L1
NEUTRAL
SIDE
ROUND
GROUNDING
PRONG
LEVEL
PROGRAM
NORMAL
HARD
SPEEDY
GENTLE
SOAK
START/PAUSE
POWER
COLD
HOT
MEDIUM
LOW
EXTRA LOW
FUNCTION
FULLY AUTOMATIC WASHING MACHINE
WASH
SPIN
HIGH
WATER
SUPPLY
2 3 4 5
6 7
8
9
1
10
WATER
RINSE
