INSTALLING THE NOISE DAMPER PLATE
CONNECTING THE WATER SUPPLY HOSES
The water supply hose must be connected to the washing machine at one end and to the water faucet
at the other. Do not stretch the water supply hose. If the hose is too short and you do not wish to
move the water faucet, replace the hose with a longer, high-pressure hose.
Select appropriate faucet as shown in the figures below. If none of these faucets are available, use
the faucet adapter provided.
The end of faucet spout should be longer than 10mm (0.4”), or the connector cannot be fixed properly.
Water leakage could develop.
1. Connect the water inlet hose to the
faucet by turning the connecting nut.
2. Then connect the other end of water
inlet hose to the cold connector in
water mixing valve by turning the
connecting nut.
Rubber ring seal
Be sure a rubber ring is inside the connecting nut.
WATER
INLET HOSE
CONNECTING
NUT
COLD WATER
CONNECTOR
LID OF
HOT WATER
CONNECTOR
CONNECTING
NUT
If you have both cold and hot water supplied, connect the inlet hoses by matching cold to cold and hot
to hot.
1. Connect the water inlet hoses to the faucets
by turning the connecting nuts.
2. Unscrew the lid of hot water connector
in water mixing valve, and then connect
the other end of water inlet hoses to the
connectors in water mixing valve by
turning the connecting nuts.
WATER INLET HOSE
WATER
INLET HOSE
CONNECTING
NUT
COLD WATER
CONNECTOR
HOT WATER
CONNECTOR
CONNECTING
NUT
CONNECTING
NUT
Be sure the rubber rings are inside the connecting nuts.
