15
CARE AND MAINTENANCE
¾ Cleaning the Exterior
• Wipe the dryer surfaces, including the control panel, with a soft cloth and non-abrasive
household detergents.
• Use a soft cloth to dry the surfaces.
• Do not pour water on the dryer.
¾ Cleaning the Filters
Unplug the power cord prior to any cleaning.
Cleaning the Lint Filter:
a) Removing the Lint Filters:
Remove by pulling outward using the four
(4) grip holes in the filter assembly.
ALL FILTERS MUST BE IN PLACE WHEN DRYING
FILTERS MUST BE CLEANED BEFORE AND
AFTER EACH USE.
b) The filter assembly consists of three (3)
parts
(See illustration)
a) Exhaust Vent Shroud
b) Lint Filter
c) Exhaust Filter
c) Separate each of the above parts and
clean the individual pieces using a SOFT
brush or vacuum cleaner. DO NOT
damage the filters
d) Re-install the filter assembly
Reassemble the filter assembly in order
Exhaust Filter – Lint Filter – Exhaust
Shroud
Align the entire assembly with the
recessed position in the back of the drum
and press firmly until the entire assembly
is secure.
Cleaning the Air Intake Filter
a) Removing the Air Intake Filter:
Remove by pulling outward holding the filter
housing by the top and bottom.
b) Remove the filter inside the housing and
clean using a SOFT brush or vacuum
cleaner.
c) Replace the filter housing by pushing
upwards with your thumb until the latch is
secure.
