Sensor Activated
Fire Extinguishing (S.A.F.E.) System
Parts Break Down
Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts
from the factory, you can FAX your order to ADC at (508) 678-9447 or telephone your order directly to the ADC
Parts Department at (508) 678-9000. Please specify the dryer model number and serial number in addition to
the description and part number, so that your order is processed accurately and promptly.
The illustrations on the following pages may not depict your particular dryer exactly. The illustrations are composite
of the various dryer models. Be sure to check the descriptions of the parts thoroughly before ordering.
We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the
right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material,
and to change or discontinue models.
Illus. No. Part No. Qty. Description
1 165114 1 Sensor Activated Fire Extinguishing (S.A.F.E.) System Solenoid Water
Valve 24V 50/60 Hz
2 143220 1 3/8” F.P.T. Brass Tee
3 143251 1 3/8” M.P.T. Brass Plug
4 143208 2 3/8” Comp x 3/8” M.P.T. Brass Connector
5 143099* 6’ 3/8” OD x 0.035 Wall Copper Tubing
6 311588 1 Sprinkler Head Mounting Plate
7 143303 1 3/8” N.P.T. Brass Lock Nut
8 143155 1 3/8” Brass Elbow 90°
9 150430 2 #10 x 1/2” Self Drilling Screw
10 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
11 143581 1 3 GPM 3/8” F.P.T. Spray Nozzle
12 142888 1 1/2” to 3/8” Bushing for Sensor Activated Fire Extinguishing (S.A.F.E.)
System Valve
13 824081 1 R.C. Network Assembly
* Sold by the foot.
