For Energy Conservation
● Make sure the lint filter is always clean.
● Do not overload dryer.
● Do not overdry clothes.
● Remove items to be ironed while still damp.
● Large loads of similar fabrics dry the most
efficiently. However, dry permanent press in
smaller loads to prevent wrinkling.
● Use the correct temperature FABRIC
SELECTOR setting for the type of fabric being
dried.
● Locate your dryer so the exhaust duct is as short
and straight as possible.
● Do not open the door during the drying cycle.
● Plan to do your laundry on low humidity days;
your clothes will dry faster.
● Should you plan to dry several loads, do them
one after another, then you do not have to reheat
the dryer’s interior parts each time.
Reinstallation of Shipping Materials
Remove front access panel by removing two screws.
Place the shock sleeves on all four shock absorbers.
Refer to Figure 8.
Insert hooked end of shipping brace into the open slot
of the motor mount. Attach with bolts and washers.
Refer to Figure 8.
Reinstall front access panel.
Figure 8
Refer to the INSTALLATION INSTRUCTIONS for
proper procedures whenever the washer is moved.
IMPORTANT: The shipping materials MUST be
reinstalled whenever the unit is moved.
H336I
1 Shock Sleeves
2 Motor Mount
3 Bolts and Lockwashers
4 Hooked End of Shipping Brace
2
1
4
3
