Programming
F232224
12
NOTE: If the wash load becomes out of balance,
the machine will attempt to balance the load. After
three failed attempts the display will light the
leftmost digit and a lower spin will be used to
complete the cycle. Refer to Figure 2.
Figure 2
*NOTE: Only supply 2 (SUP2) and supply 3
(SUP3) have independent water valves to flush
their respective compartment. Compartment 1 will
flush whenever machine is filling with water.
External chemical supply signals and any related
flush valves will activate approximately 15 seconds
after machine begins to fill with water. If
programmed water level is reached prior to 15
seconds, no chemical supply signal will be
activated.
**NOTE: ADD BLEACH LED lights if Supply 2 is
the only supply programmed. If set up for
"bEEP"(refer to SETUP Mode section), buzzer will
sound on and off for the first eight seconds. The
Supply 2 and ADD BLEACH LED remain on for
45 seconds or until the fill is complete, whichever
comes first.
***NOTE: Selecting "AFIL" (auxiliary fill) in
SETUP Mode will remove supply 5 and supply 6 as
optional supply signals.
CHM512R
1 Out-of-Balance LED
<
<
12
34
56
1
Supply Programmed External Chemical Supply Signal Compartment Flushed
SUP0 None None
SUP1 Supply 1 Compartment 1*
SUP2 Supply 2** Compartment 2
SUP3 Supply 3 Compartment 3
SUP4 Supply 4 No compartment Flush*
SUP5 Supply 5*** No compartment Flush*
SUP6 Supply 6*** No compartment Flush*
SUP7 Supply 7 Compartment 3
Table 3
