Display Indicators
Table 1 lists the various displays and what they mean.
The operator should become familiar with these
machine displays.
Display Meaning
tESt
Diagnostic test cycle selected or enabled
SPIn
Spin (extract) step
SUP1
Supply signal 1 (“S1” output), normally detergent
SUP2
Supply signal 2 (“S2” output), normally bleach
SUP3
Supply signal 3 (“S3” output), normally softener
SdLY
Spin coast (motor coasts after high speed extract)
CFIL
Cold Fill
HFIL
Hot Fill
bFIL
Warm Fill (cold + hot)
bLCH
Control will also light “add bleach” indicator
PASS
Variable-speed ONLY – balance “PASS” condition; shows in “test” cycle only
FAIL
Variable-speed ONLY – balance “FAIL” condition; shows in “test” cycle only
bAL?
Variable-speed ONLY – meaning: “Do you wish to enter balance detection test routine?”
CY__
Cycle number (followed by a space and number 1 through highest cycle number)
nor
n
Normal agitation selected
gEnt
Gentle (reduced) agitation selected
For
Wash speed forward (during test cycle)
rEv
Wash speed reverse (during test cycle)
dISt
Variable-speed ONLY – distribution speed (during test cycle)
LO
Low water level
nEd
Medium water level
HI
High water level; also denotes “HIGH” spin speed in variable speed “test” cycle.
CEL
Display all temperatures in degrees Celsius
FAr
Display all temperatures in degrees Fahrenheit
___C
The first 3 digits are reserved for temperature reading, C indicates “degrees Celsius”
___F
The first 3 digits are reserved for temperature reading, F indicates “degrees Fahrenheit”
FILL
“Fill error” – machine did not fill to programmed water level within 10 minutes; also shows
during Rapid Advance mode, refer to Programming Manual
door
“Door” opened during cycle
SHUt/door
Machine user must “shut door” of the washer to allow the cycle to begin
Table 1 (Continued)
