2 in 1 Grass Trimmer/Edger EN
76
1. REAR HANDLE
2. AUXILIARY HANDLE
3. TELESCOPIC SHAFT
4. LOCKING COLLAR
5. AUXILIARY HANDLE LOCKING LEVER
6. SAFETY GUARD
7. FLOWER GUARD
8. EDGER WHEEL
9. LINE CUTTER
10. BATTERY PACK
11. TRIMMER HEAD COVER (See Fig. K2)
12. CAP RELEASE LATCH (See Fig. K2)
13. SPOOL (See Fig. K2)
14. TRIMMER HEAD (See Fig. K2)
15. EYELET (See Fig. K2)
16. LINE FEED BUTTON (See Fig. K1)
17. WALL MOUNT BRACKET, TOOL (See Fig. L)
18. LOWER SHAFT COUPLING (See Fig. F1)
19. UPPER SHAFT (See Fig. F1)
20. MOTOR HOUSING OF TRIMMER HEAD (See Fig. H1)
