OPERATING THE TORNADO OVEN
THE CONTROL PAD
Reference Figure 10.
1. Display
Displays operation and editing information.
2. Soft Keys
Eight keys adjacent to the display. Press a soft key
to select an option on the screen adjacent to the
key.
3. Arrow Keys
Press to navigate between screens, or within screen
if editing a recipe. Also used to access “code entry”
screen when pressed simultaneously from
OFF or
COOLING DOWN mode.
4. Stop Key
Press to immediately terminate a cook cycle.
5. Numeric Keys
Use to enter data in the
EDIT mode, and to
manually input cook times if the
TIME screen is
enabled (see page 15 and 18 for more detail).
6. Back Key
Press to return to a previous screen. If in IDLE
mode, press to turn the oven off.
7. Enter Key
Used to save edited information in the
EDIT mode
and to confirm a code entry.
Press the
BACK and ENTER keys simultaneously
from the
OFF or COOLING DOWN mode to access
the “code entry” screen.
1
2
2
3
3
4
5
6
FIGURE 10: The Control Pad
