Installed whole
system total rack
space height (rack
spaces)
4U
Secondary form factor Tower
UPS / Power Module
weight (lbs)
108
UPS / Power Module
weight (kg)
49
UPS Shipping
dimensions (height x
width x depth /
inches)
12.7 x 23.6 x 29.1
UPS Shipping
dimensions (height x
width x depth / cm)
32.3 x 59.9 x 73.9
Shipping weight (lbs) 158
Shipping weight (kg) 71.7
UPS housing material Steel
Cooling method Fans
ENVIRONMENTAL
Operating
Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature
Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr.
(full load)
1767
AC economy mode
BTU / hr. (full load)
707
Battery mode BTU /
hr. (full load)
1784
AC economy mode
efficiency rating
(100% load)
96%
Operating Elevation
(ft)
0-3000m (0 to 10,000 ft.)
Audible Noise 60 dBA at front side 1 meter
Operating Elevation
(m)
0-3000 m
COMMUNICATIONS
Communications
interface
USB (HID enabled); DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface
Network monitoring
port description
Additional contact closure support with optional RELAYIOCARD and RELAYIOMINI interface cards. RELAYIOMINI
installation requires removal of panel containing USB ports
PowerAlert software Included
