TL-WR702N 150Mbps Wireless N Nano Router
- 3 -
1.2 Conventions
The Router or TL-WR702N mentioned in this guide stands for TL-WR702N 150Mbps Wireless N Nano
Router without any explanation.
Parameters provided in the pictures are just references for setting up the product, which may
differ from the actual situation.
You can set the parameters according to your demand.
1.3 Main Features
¾ Complies with IEEE 802.11n/g/b
¾ Wireless speed up to 150Mbps
¾ Powered by external power adapter or USB connection to computer
¾ Travel size design, ideal for home or travel use
¾ Compact and portable, powerful wireless signal as well
¾ Perfectly compatible with almost all the 2.4GHz Wi-Fi devices
¾ Supports AP, Router, Repeater, Bridge, and Client modes
¾ Supports WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
1.4 Panel Layout
Figure 1-1 TL-WR702N sketch
¾
LED
Status Indication
Solid The device is ready to work.
Flashing The device is booting or rebooting.
Table 1-1 The LED Description
