ACPI Features
Slow blinking LED for suspend state indicator•
BIOS support for USB keyboard•
Main switch override mechanism•
Internal/external modem ring-on•
Onboard I/O
Intel ICH9R SATA Controller, 6 connectors for 6 devices with support of RAID •
functions 0, 1, 5 and 10 (RAID 5: supported by Intel's RAID Controller in the
Windows OS environment only)
1 fl oppy port interface (up to 2.88 MB)
•
1 Fast UART 16550 compatible serial port and 1 header•
Intel 82573V and 82573L Gigabit Ethernet Controllers (Two LANS under •
LAN2)
PS/2 mouse and PS/2 keyboard ports•
Up to 7 USB (2 rear ports, 2 headers, and 1 on-board connector)•
VGA Connector•
SIM 1U IPMI Slot•
Winbond 83627HG (Super I/O), Hardware Monitor: W83793G•
XGI Volari Z9S with 32 MB DDR2•
Temperature
Monitoring CPU, chassis environment•
CPU Thermal Trip support•
Thermal Monitor 2 (TM2) (available if supported by the CPU)•
Other
Wake-on-LAN (WOL)•
Wake-on-Ring (WOR)•
Onboard +5vsb warning LED Indicator ("LE 1")•
External modem ring-on•
CD Utilities
Drivers and software for Intel 3200 chipset utilities
•
Dimensions
Micro ATX form factor, 9.6" x 9.6" (243.8 x 243.8 mm)•
