Attaching the Table-Top
Stand (Alternative)
You can change the Table-Top Stand from
the edge to the middle position by referring
to the instructions below.
Note
Two or more people are needed to carry out this
installation.
Be careful not to pinch the finger during
installation.
Note
Two or more people are needed to carry out this
installation.
Ensure that there are no objects in front of the
TV.
To bundle the cables
*1 Location of cable clamper when the Table-Top
Stand is attached to middle position.
*2 Location of cable clamper when the Table-Top
Stand is attached to edge position.
Note
To detach the cable clamper from the TV, press
the top of the clamper , then pinch as
illustrated.
Middle position
Thick cushion
1
1.5 N∙m/1,5 N∙m
{15 kgf∙cm}
2
IR Sensor
3D Sync
Transmitter
*
2
*
1
