www.snapper.com4
Set up the recoil rope handle
• Hold the bail control against the handle, and pull the recoil
rope handle out to the rope guide (A, Figure 2) on the
handle. Hook the recoil rope into the rope guide (it might
be a tight fit).
Add oil and fuel
• Move the mower outside to a flat, level surface.
• Remove the oil fill cap (A, Figure 3). Add the
entire contents of the supplied oil container to
the engine. Replace the oil fill cap.
IMPORTANT Mower is shipped without oil in
engine. Failure to add oil will result in engine
damage.
• Remove the fuel fill cap (B). Add clean, fresh,
UNLEADED fuel with a minimum of 87 octane,
leaving one inch of space from the top of the
tank for fuel expansion.
IMPORTANT Fuel tank holds less than 1/2 gallon.
IMPORTANT DO NOT mix oil with fuel.
• Replace the fuel fill cap, and wipe up any spills.
4
Figure 2
A
5
Figure 3
B
A
