Specications
Model: XE-A207W/XE-A207B
XE-A217W/XE-A217B
Dimensions: 360 (W) x 425 (D) x 330 (H) mm
Weight: Approx. 11.0 kg
Power Source: Ofcial (nominal) voltage and frequency
Power Consumption: Stand-by: 7.4 W (When the ofcial voltage is 220 to 230 V, 50 Hz/60 Hz)
7.5 W (When the ofcial voltage is 230 to 240 V, 50 Hz)
Operating: 32.4 W (max.) (When the ofcial voltage is 220 to 230 V, 50 Hz/60 Hz)
32.2 W (max.) (When the ofcial voltage is 230 to 240 V, 50 Hz)
Working Temperature: 0 to 40 °C (32 to 104 °F)
Humidity: 20 % to 90 %
Display: Operator display: LCD display with Tilt mechanism
160 (W) x 64 (H) (dots)
Customer display: 7-segment display
Printer: Type: One-station thermal printer
Printing speed: Approx. 12 lines/second
Printing capacity: 30 digits
Other functions:
- Receipt (ON-OFF) function
- Compression print for an electronic journal
Logo: Graphic logo printing:
Size: 130 (H) x 360 (W) pixel
Area of black must be less than 35% of all area.
Logo message printing:
Logo message for the receipt (max. 30 characters x 6 lines)
Paper Roll: Width: 57.5 ± 0.5 mm
Max. diameter: 80 mm
Quality: High quality (0. 06 to 0.08 mm thickness)
Cash Drawer: 5 slots for bills and 8 for coin denominations
Accessories: Basic User Manual: 1 copy
Standard key sheet: 1 (placed under keyboard cover) for XE-A217W/XE-
A217B only
Programing key sheet: 1 (placed under keyboard cover) for XE-A217W/XE-
A217B only
Paper roll: 1
Drawer lock key 2
Fixing angle bracket 1
Battery caution label 1
*Specications and appearance are subject to change without notice for improvement.
