E
25
Menu Items
BRIGHTNESS SENSOR
(When connected to the PN-ZR01 (optional) only)
WhensettoONorON:DISPLAY,thebrightnesswill
automatically change according to the lighting and
surrounding brightness. Performs operation with the primary
monitor.IfsettoON:DISPLAY,theeffectwillbedisplayed
with a
.
If connecting to multiple monitors, the brightness of all the
monitors will change.
The
will be displayed on the primary only.
WhensettingBRIGHTinSCHEDULEontheOPTIONmenu,
setBRIGHTNESSSENSORtoOFF.
BRIGHTNESS SENSOR SETTING
(When connected to the PN-ZR01 (optional) only)
Performsadjustmentstothebrightnesssensor.Performs
operation with the primary monitor.
Set the surrounding brightness and the current screen
luminancetoAMBIENTBRIGHTNESSandSCREEN
BRIGHTNESS.
IndividuallysetWHENLIGHT:andWHENDARK:.
EvenifbrighterordarkerthanthesetAMBIENT
BRIGHTNESS,thescreenbrightnesswillnotchange.
CURRENTAMBIENTBRIGHTNESSisshownforreference.
COPY SETTING VALUE
Whenthemonitorhasbeenconnectedtomultiplemonitors
withRS-232C,youcancopytheprimarysettingdetailsto
the secondary. Perform operations with the primary monitor.
SelectsthesettingstocopywithCOPYSETTINGVALUE
TARGET.
“PICTURE”ONLY
...CopiesthePICTUREmenusettings.*
ALL ........................Copiesallthesettings.*
SelecttheIDNo.ofthemonitorthatyouwouldlikecopyto
withCOPYTOIDNo.,thenselectCOPYandpress
MENU
.
If you select ALL, settings will be copied to all monitors.
WhenyouwouldliketoconrmtheIDNo.thatissettothe
monitor,selectIDNo.andpress
.TheIDNo.willbe
displayed on the screen.
*CertainsettingdetailssuchasANALOGGAIN,ANALOG
OFFSET,andDISPLAYCOLORPATTERNcannotbe
copied.
LOGO SCREEN
Sets whether or not to display the logo screen.
STANDBY MODE
WhenSTANDARDisselected,startuptimefromstandby
mode is reduced. Note, however that, more power will be
consumed in standby mode.
WhenLOWPOWERisselected,currentconsumption
is reduced while the monitor is in standby mode. Note,
however, that the startup time from standby mode becomes
longer.
IfsettoLOWPOWER,certainRS-232Ccommandscannot
be used in standby mode, and control via LAN will be
disabled.
OFF IF NO OPERATION
Determineswhetherornottosetthemonitortogointo
standby mode when there is no operation from the remote
controlunit,RS-232Ccommands,orLANforover4hours.
HOT PLUG CONTROL
SetswhethertousehotplugcontrolforthePC/AVHDMI
andPC/AVDVI-Dinputterminals.
RS-232C/LAN SELECT
Selects the method with which to control the monitor from
the computer.
ID No. SET
AssignsIDnumberstomonitorsconnectedinadaisychain
(seepage34),usingtheremotecontrolunitorRS-232
cables.
Thenumbers1to255areavailableforIDnumbers.
If“0”isset,thesystemregardsthisasthestatewherenoID
number is set.
AUTO ASSIGN ID No.
IDNo.tobeusedwillbeautomaticallyassignedwhen
multiplemonitorsareconnectedwithRS-232C.
Select ON, then press
MENU
. Perform operations with the
primary monitor.
BAUD RATE
SelectsthecommunicationspeedusedforRS-232C
communication.
LAN SETUP
Conguresthesettingstocontrolthemonitorfromthe
computerviaLAN.(Seepage45.)
AUTO ASSIGN FIXED IP ADDR.
CanbeenabledwhenRS-232C/LANSELECTisLANand
theDHCPCLIENTisOFF.
SettheDHCPCLIENTforsecondarymonitorsconnected
byRS-232CtoOFFandaxedIPaddressisautomatically
allocated.
If the IP address is a duplicate with a network device other
than a monitor, individually change the IP address.
OPTION DC OUT SETTING
Normally,leavethissettingasOFF.
Whenusinganoptionalpart,ifinstructionappears,change
the setting accordingly.
HDMI AUTO VIEW
WhenONisselected,thescreensizeisadjusted
automaticallyaccordingtothescreensizecontrolsignal
includedinthevideosignalinputfromtheAVHDMIinput
terminal.
