Specifications
Item
LC-70LE735X
Resolution 1,920 x 1,080
Video colour system PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV function TV-standard Analogue PAL ( B/G, D/K, I), SECAM ( B/G, D/K, K/K1), NTSC:(M)
Digital DVB-T
Receiving
channel
VHF/UHF 44.25–863.25 MHz
TV tuning system Auto preset 02ch/07ch/09ch/10ch/28ch at Australia.
STEREO/BILINGUAL NICAM ( B/G, I, D/K), A2 stereo (B/G), BTSC
Audio amplifier 10 W x 2
Speaker (3.4 cm x 15 cm) x 2
Terminals ANT (Antenna input)
UHF/VHF 75 q Din type
RS-232C D-Sub 9 pin male connector
INPUT 1 VIDEO in, AUDIO in
INPUT 2 VIDEO in, AUDIO in
INPUT 3 AUDIO in, COMPONENT in (480I, 576I, 480P, 576P, 720P/50 Hz, 720P/60 Hz,
1080I/50 Hz, 1080I/60 Hz)
HDMI 1 (INPUT 4) (ARC) HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50 Hz, 720P/60 Hz, 1080I/50
Hz, 1080I/60 Hz, 1080P/50 Hz, 1080P/60 Hz, 1080P/24 Hz)
HDMI 2 (INPUT 5) HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50 Hz, 720P/60 Hz, 1080I/50
Hz, 1080I/60 Hz, 1080P/50 Hz, 1080P/60 Hz, 1080P/24 Hz), AUDIO in (shared
usage with PC) (Ø 3.5 mm jack)
HDMI 3 (INPUT 6) HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50 Hz, 720P/60 Hz, 1080I/50
Hz, 1080I/60 Hz, 1080P/50 Hz, 1080P/60 Hz, 1080P/24 Hz)
HDMI 4 (INPUT 7) HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50 Hz, 720P/60 Hz, 1080I/50
Hz, 1080I/60 Hz, 1080P/50 Hz, 1080P/60 Hz, 1080P/24 Hz)
PC (INPUT 8) 15 pin mini D-sub, AUDIO in (shared usage with HDMI 2) (Ø 3.5 mm jack)
USB 1 USB (type A)
USB 2 (HDD) USB (type A)
USB 3 (WIRELESS LAN) USB (type A)
ETHERNET (10/100 BASE-T) Network connector
AUDIO IN (HDMI 2/PC) Ø 3.5 mm jack*
1
DIGITAL AUDIO OUTPUT Optical S/PDIF digital audio output
OUTPUT/Headphones Ø 3.5 mm jack (audio output)
OSD language English/Simplified Chinese/Arabic/Persian/French/Indonesian
Power requirement AC 110–240 V, 50/60 Hz
Power consumption (method IEC62087) 240 W (0.3 W Stand by)
Weight With Stand 42.5 kg
Without Stand 40.0 kg
Operating temperature
0°C to e 40°C
I
The HDMI 2 and PC terminals can both use the same audio input terminal.
• As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There
may be some deviations from these values in individual units.
