3D Glasses
Supplied Accessories for 3D Glasses
Make sure the following accessories are provided with the 3D Glasses. Two sets of 3D Glasses are provided.
Nose pad *
(Large ×2, small ×2)
Page 42
Cleaning cloth
(×2)
Glasses case
(×2)
3D Glasses band *
(×2)
Page 42
* Use the 3D Glasses band and nose pad as needed.
Precision screwdriver
(Phillips ×2, slotted ×2)
Page 42
3D Glasses
(×2)
Pages 42 to 44
• The illustrations above are for explanation purposes and may vary slightly from the actual accessories.
Please contact your local authority for the correct method of disposal of this product and/or packaging.
Part Names
•
Enjoying 3D Image Viewing
1 2
4
5
3
6
1 Power button
Press for at least 2 seconds to turn on and off the 3D
Glasses.
When the 3D Glasses are turned on, pressing this
button switches between 2D and 3D modes.
2 LED light
Blinks 3 times when the power is turned on.
Blinks 2 times when 2D mode is selected.
Blinks 3 times when 3D mode is selected.
Blinks 6 times when the battery power is low.
Lights for 2 seconds when the power is turned off.
3 Service terminal
This terminal is for service use only.
Please do not connect any other device to this terminal.
4 Infrared receiver
Receives an infrared signal sent from the TV. The 3D
Glasses turn off automatically after 3 minutes if no signal
is received from the TV.
5 Nose pad mount
The dedicated nose pad can be mounted here. (See
page 42.)
6 3D Glasses band mount
The dedicated 3D Glasses band can be mounted here.
(See page 42.)
• Do not soil or apply stickers or other obstacles to the
infrared receiver. Doing so may block signals from the TV
and prevent the 3D Glasses from working correctly.
• Interference from other infrared communications equipment
may prevent you from viewing 3D images correctly.
•
•
•
•
•
•
•
