Your Phone
Phone Layout
The following illustrations show the main elements
of your phone:
Earpiece
Main display
Soft key (right)
WAP Browser
key
Alphanumeric
keys
Soft key (left)
Dial/Menu
confirmation key
Cancel/Back/
Correction key
Folder
Navigation keys
(Up/Down/Left/
Right)
Volume/Menu
browse keys
Special
function keys
Power On/Off /
Menu exit key
Open View
Service light
Charger Connector
Microphone
Your Phone
11
Key(s) Description
(soft keys)
Perform the functions indicated by the
text above them, on the bottom line of
the display.
In Menu Mode, scrolls through the
menu options and Phonebook memory
with the Up and Down key, returns to
the previous menu level and selects
the current menu respectively with the
Right and Left key.
In Idle Mode, the Up and Down key
allows you to access your favourite
menu options directly. For further
details about shortcuts, see page 104.
In Idle Mode, launches the WAP
(Wireless Application Protocol)
browser directly.
Makes or answers a call.
In Idle Mode, accesses the call log list.
In Menu Mode, selects a menu
function or stores information that you
have entered, such as a name in the
phone or SIM memory.
Closed View
Antenna
Service light
Ear-microphone
jeack
