ENGLISH
C 6 Replace the set back into the Razor Head
Assembly so that the ‘wings’ on the comb
fit within the brackets located towards the
center of the Assembly.
The set will only fit into the Razor Head Assembly
if the ‘wings’ are between the brackets. Make sure
that the two pointy edges of the head fit exactly
into the recesses.
7 Repeat the process for the other two sets
of cutters and combs.
8 Replace the frame.
C 9 Press down (1) and turn the black
3-pronged locking bracket clockwise (2)
until it locks into place.
10 Close the Razor Head Assembly.
Once A Month: Razor Head
For optimum performance, razor cutters and
combs should be cleaned in a degreasing liquid
(e.g. rubbing alcohol) and lubricated with one
drop of mineral oil (in the center of the head).
This helps prevent wear of the shaving heads.
After Each Use: Trimmer
1 Turn razor OFF.
20
ENGLISH
2 Push down spring-release trimmer switch.
C 3 Clean trimmer with the brush every time
you use it.
C 4 Lubricate the trimmer teeth with one
drop of mineral oil every 6 months.
5 Close trimmer by pressing trimmer down.
This razor has no other user-serviceable parts.
For assistance call 1-800-243-3050.
Replacing the Razor Heads
◗ Replace the razor heads once a year for
optimal shaving results.
◗ Replace damaged or worn razor heads with
model HQ9 Philips Norelco razor heads only.
Razor head check indication
C
◗ The replacement head indicator light starts
blinking to remind you to check if it’s time to
replace your razor heads to obtain optimal
shaving results.
21
