8 Camera Configuration
The CAMERA CONFIG menu is displayed when you select
it in the SYSTEM menu.
When more than one unit are used, each camera input is
given a camera number in this menu.
1. Move the cursor to CAM NO. Select a number with the
[–] or [+] button. The default setting is that both CAM-
ERA IN and CAM NO. are given the same number.
Available numbers: 1-128 and – (not connected)
2. Repeat the above step until all CAMERA IN are
assigned numbers.
3. Press ESC to return to the SYSTEM menu.
8 Daisy Mode
This setup lets the unit know whether the data communica-
tion line is connected in a daisy fashion.
1. Move the cursor to DAISY. Select ON or OFF with the
[–] or [+] button. The default setting is ON.
ON: Set this when daisy connection is used.
OFF: Set this for other than daisy chain.
8 Terminal Mode
This setup specifies the function of ALARM/REMOTE termi-
nal on the rear of the unit. Input/output is specified with
internal connection. Refer to page 16 for details.
1. Move the cursor to TERMINAL. Select ALARM or
REMOTE with the [–] or [+] button, then press SET. The
default setting is ALARM.
ALARM: Terminals are used as alarm inputs or outputs.
REMOTE: Terminals are used as remote inputs or out-
puts.
■ Setup Menus for Camera
Communication Protocol
● Communication setup
(Camera Communication)
Communication parameters for a Camera Communication
Protocol system are set in this menu.
1. Hold down the SET button for 2 seconds to open the
setup menu.
2. Move the cursor to COMMUNICATION , then press
SET. The communication setup appears.
CAMERA IN CAM NO.
