13.1.16 Private Network Features—Network ICD Group
Description
An
Incoming Call Distribution (ICD) Group can include up to 4 destinations at other PBXs in a private network,
including the floating extension number of another ICD Group. This is done by assigning a virtual PS as a
member of the ICD Group, and then setting the number of a destination at another PBX as the forwarding
destination for that virtual PS. This allows multiple ICD groups at remote locations to receive calls together.
PBX-2
PBX-1
Private network
PBX-5
PBX-4
PBX-3
ICD
Group
ICD
Group
ICD
Group
ICD
Group
Telephone Company
ICD Group
Virtual PS 1
Virtual PS 2
Virtual PS 3
Virtual PS 4
Conditions
• Hardware Requirement
The KX-TDA6920, KX-TDA0920, or KX-TDA5920
SD Memory Card for Software Upgrade to Enhanced
Version must be installed in the PBX that will support virtual PSs.
• The conditions for 9.1.4 ICD Group Features—Outside Destinations also apply to this feature.
PC Programming Manual References
4.17 [2-9] System Options—Option 4—
Send CLIP of CO Caller to ISDN—when ICD Group with Cellular
Phone (KX-TDA100/KX-TDA200
/KX-TDA600 only)
Document Version 2008-11 Feature Manual 251
