Packard Bell EasyNote M5/M7 Disassembly Manual
5
Removing the Battery
Perform the following steps to remove the battery:
1. Make sure to power off the unit.
2. Turn the unit upside down.
3. Unlock the battery and slide it out of its place as the arrow shows in Fig. 1
Fig. 1 Removing the battery
Removing the Hard Disk Drive
To remove the hard disk drive, first remove the battery (see Removing the Battery), then
perform the following steps:
1. Remove the screws as shown in Fig. 2
Fig. 2 Removing the Hard disk drive cover
A=M2.5x7 black
B=M2.5x5 black
