2-19
Hardware Setup
Jumper
LVDS Power Selection Jumper: JVDD1 (for option C, E)
Use this jumper to specify the operation voltage of the LVDS interfaced flat panel.
COM Port Power Jumper: JCOMP2 (for option A),
JCOMP1, JCOMP3~6 (for option A, B, C, E)
These jumpers specify the operation voltage of the onboard serial ports.
+12V
JVDD1
1
1
+3.3V
1
+5V
1
JCOMP1
(for COM5)
JCOMP2
(for COM6)
1
+5V
1
+12V
1
1
1
+5V +12V
JCOMP3~6
(for COM1~4)
1
