qCapacities
(Approximate Quantities)
Item Capacity
Engine oil
With oil filter replacement 5.2 L (5.5US qt, 4.6 Imp qt)
Without oil filter replacement 4.7 L (5.0 US qt, 4.2 Imp qt)
Coolant
With Towing Package 12.2 L (12.9 US qt, 10.7 Impqt)
Without Towing Package 11.6 L (12.3 US qt, 10.2Imp qt)
Automatic transaxle fluid 7.0 L (7.4 US qt, 6.2 Impqt)
Transfercase oil 0.532 L (0.562 US qt, 0.468 Imp qt)
Rear differential oil 1.0 L (1.1 US qt, 0.9Imp qt)
Washer fluid 4.5L (4.8 US qt, 4.0 Imp qt)
Fuel tank 76.0 L (20.1 US gal, 16.7Imp gal)
Check oil and fluid levels with dipsticksor reservoir gauges.
qDimensions
Item Vehicle specification
Overall length 5,074 mm (199.8 in)
Overall width 1,936 mm (76.2 in)
Overall height 1,728 mm (68.0 in)
Front tread 1,654 mm (65.1 in)
Rear tread 1,644 mm(64.7 in)
Wheelbase 2,875 mm (113.2 in)
qWeights
Item
Weight
2WD AWD
GVWR (Gross VehicleWeight Rating) 2,645 kg (5,831 lbs) 2,744 kg (6,049lbs)
GAWR (Gross Axle Weight Rating)
Front 1,276 kg (2,813 lbs) 1,307 kg (2,881 lbs)
Rear 1,400kg (3,086 lbs) 1,458 kg (3,214 lbs)
qAir Conditioner
Item Classification
Refrigerant Type HFC134a(R-134a)
Specifications
