COOKTOP, BURNER AND GRATE PARTS
2
For Model: KGCP484KSS02
(Stainless Steel)
8186163
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT8284959
Wiring Diagram
LIT8285588
Use & Care Guide
LIT8284979
Installation
Instructions
LIT8285589
Instructions,
LP Conversion
2 8284730 Backsplash
3 8284760 Support,Backsplash
4 3196537 Screw, 8−18 x 3/8
5 4454963 Grate, Burner
6 8285066 Trim, Island
7 3400843 Screw, 8−18 x 1/4
9 8285486 Support, Control
Panel
10 8284741 Grate, Grill
11 4449040 Screw
12 8285005 Bracket, Spark
Module
13 Cap, Burner
4455243 14K (2)
8284669 6K (2)
14 8284985 Cooktop (12")
(2 Lg Burners)
15 Holder, Orifice
Includes Orifice
4456622 Turbo (3)
4456920 Auxillary
16 8285042 Support Rail
17 Trim, Side
8285489 Right Hand
8285490 Left Hand
18 8284812 Cooktop (12")
(Sm & Lrg Burners)
19 Burner Head 14K
4455849 Turbo (2)
4455979 Auxillary
20 3368921 Screw, 7−18 x 3/4
21 2005292 Nameplate
22 2004333 Palnut
23 8284939 Control Frame
24 8284903 Panel, Control
25 3196176 Screw, 8−18 x 1/2
26 4455192 Bezel, Knob
27 4454970 Knob, Burner
28 4455109 Plate, Simmer
30 8284918 Frame, Wave Tray
31 8284919 Plate, Wave
32 8284917 Plate, Wave tray
3177991 Screw
33 8284742 Knob, Grill
34 8522422 Module, Spark
2 burner (2)
35 8285038 Cover, Burner
Spud
36 8284743 Knob, Griddle
