* Specification & design are subject to change without notice
In the event that you experience difficulty in the operation or configuration of
your unit, we would be happy to assist you. Before you contact us, please
read through the manual and the Frequently Asked Questions first to see if
your question is already addressed.
Email Support: support@ken-a-vision.com
Phone Support: 1-800-627-1953 (8:00AM to 4:30PM CST, M-F)
Be sure to visit our website for resources, downloads, and troubleshooting
information:
http://www.ken-a-vision.com/servicesupport.htm
Network Video Flex
Network Video Flex
®
®
Instruction Manual
7700
VF7700InstrManual.04v1
Part# INS-
Video Flex 7700 Specifications (Network Interface)
Model 7700
CPU 32Bit RISC Processor
OS Embedded Linux
Hardware
Flash Memory 4MB
Viewer Web Browser based Monitoring
Protocol TCP/IP, HTTP, FTP, SMTP, PPP, UDP Network
Interface 10 base-T Ethernet (RJ-45)
Algorithm M-JPEG Compression
Rate 1/10 ~ 1/200
Input 1CH. NTSC/PAL
Output 1CH. NTSC/PAL
Size 640 ´ 480, 320 ´ 240, 160 ´ 120
Video
Frame Rate 30 frame/sec (320 ´ 240)
Power DC12V / 500mA
Ken-A-Vision Support
NOTES 9
