17
Playback
The easiest, most basic operation possible with your VCR is tape playback. Previously-recorded signals on a video tape are read by
your VCR and displayed on your TV just like a TV program.
LOAD A CASSETTE
1
Insert a cassette with its window side up, and label side
facing you. Press gradually on the middle of the cassette
until the VCR pulls the cassette in.
Ⅲ The VCR power will come on automatically.
Ⅲ "READING TAPE#..." will appear on the screen unless
INDEX Plus+ functions are set to OFF. (
੬ p.12 of
INDEX Plus+ instruction manual.)
Ⅲ The counter will be reset to "0
H 00M 00S" automatically.
Ⅲ If the safety tab on the cassette is absent, playback will
start automatically.
TO START PLAYBACK
2
Press PLAY.
TO STOP PLAYBACK
3
Press STOP.
TO REWIND OR FAST-FORWARD
4
Press REW to rewind the tape.
5
Press FF to fast-forward the tape.
Ⅲ Press STOP to stop the tape.
Ⅲ To rewind or fast-forward the tape using the VCR's control,
turn the SHUTTLE ring fully to the corresponding direction,
and release it.
TO EJECT THE TAPE
6
Press the VCR's STOP/EJECT button again.
+
–
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
3
54
6
2
1
POWER ON;
SELECT CHANNEL
3 OR 4 (OR AV MODE)
CH/SET –/+
POR INSTRUCCIONES EN
ESPAÑOL VEA p. 40 – 41.
CH –/+
SHUTTLE
This overrides your VCR's automatic tracking.
During Playback...
1 Press the VCR's CH(annel) +/– buttons simultaneously to
cancel auto tracking.
Ⅲ The remote control's CH +/– cannot be used for this purpose.
2 Press CH + or – to adjust tracking.
Ⅲ Press the VCR's CH +/– simultaneously to return to
automatic tracking.
During Slow...
1 Simply press CH + or – to adjust tracking.
To adjust tracking manually
1
23
4
56
7
89
0
