Duplex SC/PC connector (RX and TX)Cables and connectors
Status LED, one bicolor:
■
Off—PIC is not enabled
■
Green—PIC is operating normally
■
Red—PIC has an error or failure
Port LEDs, one pair:
■
Link—If green, the port is online; if there is no light, the port is down
■
RX—If flashing green, the port is receiving data; if there is no light, the port might be on
but is not receiving data
LEDs
Table 29: Optical Interface Support for 10-Gigabit Ethernet DWDM PICs
Extra-Long Wavelength Serial DWDM, LAN RateParameter
Single-modeOptical interface
Dense wavelength division multiplexing (DWDM)Transceiver type
ITU-T G.694.1Standard
9/125 SMF cable: 49.6 miles/80 kmMaximum distance
1528.77 through 1563.86 nm, 100-GHz ITU gridTransmitter wavelength
0 through 4 dBmAverage launch power
9 dBmTransmit extinction ratio
–7 dBm through –24 dBmAverage receive power
–7 dBmReceiver saturation
–24 dBmReceiver sensitivity
