2 Intel
®
Server Board S5000PAL User’s Guide
Table 2 summarizes the features of the server board.
Table 2. Server Board Features
Feature Description
Processor Support for up to two Dual-Core Intel
®
Xeon
®
processors 5000 or
5100 sequence with a 677-, 1066-, or 1333-MHz front side bus.
Up to two Quad-Core Intel
®
Xeon
®
processors 5300 sequence with
a 1066- or 1333-MHz front side bus.
Up to two 45nm 2P Dual-Core Intel
®
Xeon
®
processors. Product
codes S5000PALR and S5000XALR only.
Up to two 45nm next generation Quad-Core Intel
®
Xeon
®
processors. Product codes S5000PALR and S5000XALR only.
Memory
• Eight DIMM slots supporting stacked DDR2 533/667 MHz
FBDIMM memory
• Support for up to 32 GB DDR2 533/667 MHz FBDIMM memory
Chipset Intel
®
5000P or Intel
®
5000X chipset, consisting of:
• Intel
®
5000P or Intel
®
5000X Memory Controller Hub (MCH)
• Intel
®
6321ESB I/O Controller Hub
Peripheral Interfaces External connections:
• Stacked PS/2* ports for keyboard and mouse
• RJ45 Serial B port
• Two RJ45 NIC connectors for 10/100/1000 Mb connections
• Two USB 2.0 ports
Internal connections:
• One USB port header, which supports two USB 2.0 ports
• One DH10 Serial A header
• Six Serial ATA 150 connectors with integrated RAID 0/1
support
• One ATA-100 44-pin connector for optical drive support
• SSI-compliant 24-pin control panel header
• SSI-compliant 24-pin main power connector, supporting the
ATX-12V standard on the first 20 pins
I/O Controll National Semiconductor* PC87427 controller
Video On-board ATI* ES1000 video controller with 16 MB DDR SDRAM
Hard drive
• Support for six SATA-150 hard drives
LAN Intel
®
82563EB dual port controller for 10/100/1000 Mbit/sec
Ethernet LAN connectivity
Expansion Capabilities
• One low profile riser slot supporting 1U or 2U PCI Express*
riser cards
• One full height riser slot supporting 1U or 2U PCI-X* and PCI
Express* riser cards
Fans Support for two processor fans and four system fans
